Plastic molds are tools used in the plastics processing industry to match plastic molding machines, giving plastic products a complete configuration and precise dimensions. However, we usually encounter the phenomenon of mold rust, which not only affects the appearance of the mold, but also directly affects the overall quality of the mold, so the rust of the mold is a problem that cannot be ignored. The following are the reasons and measures for analysis.
1. Causes of mold rust
(1) Hand sweat.
(2) The resurgence of the mold.
(3) A product of decomposition of a molding material.
2, related analysis
(1) The corrosion of the mold (gas, residue) of the molding material is the most common. In order to prevent rusting of the mold, the most common method is to chrome the mold cavity, but the chrome treatment cannot solve the problem sufficiently, because the decomposition product is also corroded to the deep part of the pin hole, and these places are places that cannot be plated. .
(2) When the mold is cooled below the regain point, moisture in the air regains moisture on the surface of the mold and water droplets are generated, causing rust.
3, the solution
(1) Short-term countermeasures: Gently rub the surface of the cavity with a cloth. The molding material is sufficiently dried to lower the temperature of the barrel to prevent decomposition of the material.
(2) Long-term countermeasures: The material of the product is turned into a material that does not corrode the mold.
4, plastic material differences
Materials that are easily decomposed, such as PVC, POM, EVA, PC, and foamed materials. Since the decomposition product has a corrosive effect on the mold, the mold should be chrome-plated.
5, reference matters
(1) When the molding is temporarily stopped, the mold cavity is sprayed with a rust preventive agent, and then the mold is closed.
(2) When the mold is stopped for a long time, apply a layer of butter to the outside of the mold and the moving parts.
(3) Method of taking out the material remaining in the nozzle
1) Use a thick copper rod tip on the nozzle side to align the mold tip with a light tap. After a slight movement, use a thin copper rod to pry it out.
2) In order to achieve this, a small number of thin copper rods (such as a diameter of 4 mm, a length of 300 mm, a brass rod with a sharpened tip) and a thicker brass rod should be provided on the injection molding machine. Diameter 12MM front grinding tip).
3) If a screwdriver is used instead, the mold will cause a major damage accident.
4) When it is impossible to pry out from the nozzle side, use an iron wire (about 4 mm in front diameter) and heat it with a heater such as an alcohol lamp to pour the nozzle from the mold cavity side. After cooling, clamp it out with pliers. At this time, the lower part of the pliers must be placed in a brass plate (or strip) to prevent damage to the mold.
5) When the nozzle material cannot be taken out by the above method, use a solvent (such as acetone) of this material to coat it. After the material is dissolved for a while, slowly remove it with a brass rod, but pay attention to the fire. near.
6) After taking out, blow it off with gas in the nozzle hole, spray it into the mold release agent, and carry out normal production.
